1/2 Round Information
Order Code: HR
Required dimensions: (W) width and (H) height
Note that the height is equal to ½ the width in a true ½ round. We allow a 1” variation on the height, either (+) or (-).
Available Patterns
Full Round Information
Order Code: RND
Required dimensions: (W) width and (H) height
Note that the width and height are equal.
Available Patterns
Quarter Round Information
Order Code: QR [L/R]
Required dimensions: (W) width and (H) height
Note that there is a "right" configuration where the height is on the left and a "left" configuration where the height is on the right.
Available Patterns
Oval Information
Order Code: OVL
Required dimensions: (W) width, (H) height, MAJOR Radius and MINOR Radius
Available Patterns
Gothic Information
Order Code: GTH
Required dimensions: (W) width, (H) height, (Leg) leg height and optional Radius
Ellipse Information
Order Code: ELL
Required dimensions: (W) width, (H) height, MAJOR Radius and MINOR Radius.
Parallelogram Information
Order Code: PRL [L/R]
Required dimensions: (W) width and (H) height and (Dim 3) angular length
Eyebrow Information
Order Code: EYE
Required dimensions: (W) width and (H) height
Available Patterns
Octagon Information
Order Code: OCT
Required dimensions: (W) width and (H) height
Note that the width and height are equal.
Available Patterns
Hexagon Information
Order Code: HEX
Required dimensions: (W) width and (H) height
Trapezoid Information
Order Code: TRP [L/R]
Required dimensions: (W) width, (H) height and (Leg) leg height
Note that the leg height is the shorter and the height is the longer of the two sides. Also, there is a “right” configuration where the leg is on the right and a “left” configuration where the leg is on the left.
Triangle Information
Order Code: See Images
Required dimensions: (W) width and (H) height
Pentoid Information
Order Code: PNT
Required dimensions: (W) width, (H) height and (Leg) leg height
Rectangle Information
Order Code: REC
Required dimensions: (W) width and (H) height
